Pramac OFF GRID LX 45/90 OPZV Battery Storage Unit
1 Images
- Price: Ā£47,000.00 Excl. VAT
- Condition: New
- Stock: Contact us for Availability.
- Stock Number: LX 45/90
Pramac OFF GRID LX 45/90 OPZV Battery Storage Unit
Off Grid LX is a universal Battery Energy Storage system (BESS) ideally suited to a range of applications, delivering reliable power in the most cost effective and environmentally sensitive way. Energy stored within the unit is converted electronically into AC power. Power can be derived from connection to an external grid supply, from a diesel generator or solar PV or wind turbine. Energy is automatically managed from any or all of these energy sources to ensure the most efficient, lowest maintenance and best environmental impact is achieved. Remote communication ensures real time monitoring and maintenance can be effected fromany location in the world.
- Deep cycle maintenance free OPzV-S battery
- Advanced EMS with touch screen control
- GSM Remote monitoring
- Full system DC isolator with pre-charge
- Auto Full system bypass
- Technical Data
Manufacturer Pramac - OFF GRID LX 45/90 Prime 45.0 kVA / 90.0 kW Phase Three-Phase Voltage 400/230 V Frequency 50 Hz Battery Chemistry OPZV Nominal Storage Capacity 90 kWh Depth of Discharge 80 DoD % Energy Usable AC 72 kWH Cycle Life 2000 Cycles Length 2012 mm Width 1183 mm Height 2012 mm Weight 3995 kg - Downloadable Documents
