Pramac OFF GRID MX 10/40 OPZV Battery Storage Unit
1 Images
- Price: Ā£35,415.00 Excl. VAT
- Condition: New
- Stock: Contact us for Availability.
- Stock Number: MX 10/40 OPZV
Pramac OFF GRID MX 10/40 OPZV Battery Storage Unit
Off Grid MX is a universal Battery Energy Storage system (BESS) ideally suited to a range of applications, delivering reliable power in the most cost effective and environmentally sensitive way. Energy stored within the unit is converted electronically into AC power. Power can be derived from connection to an external grid supply, from a diesel generator or solar PV or wind turbine. Energy is automatically managed from any or all of these energy sources to ensure the most efficient, lowest maintenance and best environmental impact is achieved. Remote communication ensures real time monitoring and maintenance can be effected fromany location in the world.
- Deep cycle maintenance free OPzV-S battery
- Advanced EMS with touch screen control
- GSM Remote monitoring
- Full system DC isolator with pre-charge
- Auto Full system bypass
- Technical Data
Manufacturer Pramac - OFF GRID MX 10/40 Prime 10.0 kVA / 40.0 kW Phase Single-Phase Voltage 230 V Frequency 50 Hz Battery Chemistry OPZV Nominal Storage Capacity 40 kWh Depth of Discharge 80 DoD % Energy Usable AC 32 kWh Cycle Life 2000 Cycles Length 1600 mm Width 1020 mm Height 1708 mm Weight 1930 kg - Downloadable Documents
