Pramac OFF GRID LX 20/60 OPZV Battery Storage Unit
1 Images

  • Price: Ā£40,203.00 Excl. VAT
  • Condition: New
  • Stock: Contact us for Availability.
  • Stock Number: LX 20/60 OPZV

Pramac OFF GRID LX 20/60 OPZV Battery Storage Unit

Off Grid LX is a universal Battery Energy Storage system (BESS) ideally suited to a range of applications, delivering reliable power in the most cost effective and environmentally sensitive way. Energy stored within the unit is converted electronically into AC power. Power can be derived from connection to an external grid supply, from a diesel generator or solar PV or wind turbine. Energy is automatically managed from any or all of these energy sources to ensure the most efficient, lowest maintenance and best environmental impact is achieved. Remote communication ensures real time monitoring and maintenance can be effected fromany location in the world.

  • Deep cycle maintenance free OPzV-S battery
  • Advanced EMS with touch screen control
  • GSM Remote monitoring
  • Full system DC isolator with pre-charge
  • Auto Full system bypass

  • Technical Data
    Manufacturer Pramac - OFF GRID LX 20/60
    Prime 20.0 kVA / 60.0 kW
    Phase Single-Phase
    Voltage 230 V
    Frequency 50 Hz
    Battery Chemistry OPZV
    Nominal Storage Capacity 60 kWh
    Depth of Discharge 80 DoD %
    Energy Usable AC 48 kWh
    Cycle Life 2000 Cycles
    Length 2012 mm
    Width 1183 mm
    Height 2012 mm
    Weight 3039 kg
  • Downloadable Documents
